Automating EC2 Auto Scaling Group Capacity Using AWS Lambda and Boto3

Introduction

Scaling EC2 Auto Scaling Groups (ASGs) dynamically can enhance performance and reduce unnecessary costs. This blog provides an AWS Lambda function to adjust the capacity of ASGs based on time-based triggers and custom tags.

Overview

The Lambda function performs the following steps:

1. Lists all EC2 Auto Scaling Groups in the account.
2. Retrieves tags for each group.
3. Checks for specific tags indicating when to adjust the capacity.
4. Updates the ASG’s capacity using the update_auto_scaling_group API.

Prerequisites

• IAM Role: Ensure the Lambda function has sufficient permissions to describe ASGs, list tags, and update ASG capacity.
• Tagged ASGs: Add specific tags to your ASGs to indicate when to update capacity.
• Boto3: AWS SDK for Python to interact with AWS services.

Lambda Function Code

import boto3
import os
from datetime import datetime, timezone

# Initialize AWS clients

def list_all_auto_scaling_groups():
    groups = []
    response = autoscaling_client.describe_auto_scaling_groups()
    for group in response['AutoScalingGroups']:
        groups.append({
            'AutoScalingGroupName': group['AutoScalingGroupName'],
            'AutoScalingGroupARN': group['AutoScalingGroupARN']
        })
    return groups

def get_asg_tags(asg_name):
    try:
        response = autoscaling_client.describe_tags(
            Filters=[{'Name': 'auto-scaling-group', 'Values': [asg_name]}]  # Corrected filter
        )
        tags = {tag['Key']: tag['Value'] for tag in response.get('Tags', [])}  # Extract tags properly
        return tags
    except Exception as e:
        print(f"Error retrieving tags for {asg_name}: {str(e)}")
        return {}

def update_asg_capacity(group_name, min_capacity, max_capacity, desired_capacity):
    print(f"Updating capacity for {group_name} to min: {min_capacity}, max: {max_capacity}, desired: {desired_capacity}")
    response = autoscaling_client.update_auto_scaling_group(
        AutoScalingGroupName=group_name,
        MinSize=int(min_capacity),
        MaxSize=int(max_capacity),
        DesiredCapacity=int(desired_capacity)
    )
    print(f"Update successful for {group_name}: {response}")

def lambda_handler(event, context):
    try:
        current_time = datetime.now(timezone.utc).strftime("%H:%M")
        print(f"Current Time (UTC): {current_time}")

        groups = list_all_auto_scaling_groups()
        print(f"Found {len(groups)} EC2 Auto Scaling Groups.")

        for group in groups:
            group_name = group['AutoScalingGroupName']
            print(f"Checking Auto Scaling Group: {group_name}")

            tags = get_asg_tags(group_name)
            print(f"Tags for {group_name}: {tags}")

            if tags.get('update_instance_count', 'no').lower() == 'yes':
                print(f"'update_instance_count' is set to 'yes' for {group_name}.")
                morning_time = tags.get('morning_time')
                night_time = tags.get('night_time')
                min_capacity_morning = tags.get('min_instances_morning')
                min_capacity_night = tags.get('min_instances_night')
                max_count = tags.get('max_count', 1)
                desired_capacity = tags.get('desired_capacity')

                if not (morning_time and night_time and min_capacity_morning and min_capacity_night):
                    print(f"Missing required tags for Auto Scaling Group {group_name}. Skipping...")
                    continue

                if current_time == morning_time:
                    update_asg_capacity(group_name, min_capacity_morning, max_count, min_capacity_morning)
                elif current_time == night_time:
                    update_asg_capacity(group_name, min_capacity_night, max_count, min_capacity_night)
                else:
                    print(f"No action needed for {group_name} at this time.")
            else:
                print(f"'update_instance_count' is not set to 'yes' for {group_name}. Skipping...")

        print("EC2 Auto Scaling Group capacity update check completed successfully.")
        return {
            'statusCode': 200,
            'body': 'EC2 Auto Scaling Group capacity updated successfully where applicable!'
        }
    except Exception as e:
        print(f"Error occurred: {str(e)}")
        return {
            'statusCode': 500,
            'body': f"Error: {str(e)}"
        }

Key Concepts

Tags for Time-Based Control:

• update_instance_count: Set to yes to enable updates for the ASG.
• morning_time and night_time: Define when to update capacity (e.g., 06:00 and 18:00).
• min_instances_morning and min_instances_night: Minimum capacity for morning and night periods.
• max_count: Maximum capacity.

How to Deploy

Create Lambda Function

• Open AWS Lambda and create a new function.
• Upload the code or use the in-line editor.

IAM Role

• Attach an IAM policy with permissions for autoscaling:DescribeAutoScalingGroups, autoscaling:DescribeTags, and autoscaling:UpdateAutoScalingGroup.

Test the Function

• Trigger the Lambda function manually to verify it lists ASGs, reads tags, and updates capacity as expected.

Conclusion

By using this approach, you can automate capacity changes for EC2 ASGs, ensuring optimal performance and cost efficiency. This setup reduces manual effort, controls costs, and adapts to changing workloads.
